parameter |
specification |
|
Control protocol |
ARTNET
|
|
Controllable chip |
WS2811/WS2812 etc
|
|
Device port |
2 RJ45 uplink 100M ports: connect STP / UTP category 5 twisted pair
|
|
Transmission distance |
100m
|
|
MTBF |
100,000 hours |
|
power supply |
DC12V 1A（external） |
|
Power consumption |
3W |
|
Operating temperature |
-10~55℃ |
|
Working humidity |
5%~90% |
|
Storage temperature |
-40~70℃ |
|
Storage humidity |
5%~90% non-condensing |
|
size |
100mm(L)*80mm(W)*25mm(H)
|
Product number |
Power supply |
Orderable |
LNX-300D |
External DC12V 1A |
✔ |
